Poultry Manure Pellet Machine


Poultry manure pellet machine is specially designed to process and produce poultry manure pellets. It can convert the headache of poultry manure into valuable poultry manure pellets, poultry manure pellets can not only be used as highly efficient organic fertilizer, but also in line with contemporary environmental trends as energy-saving biomass fuel.

  • Application: making chicken manure pellets, pig manure pellets, cow manure pellets, horse manure pellets, etc.
  • Production capacity:1-12T/H
poultry manure pellet
poultry manure pellet machine

Video Of poultry manure pellet machine for sale

Poultry manure pellet machine consists of feeder (feeding materials to the inside of the pellet machine), pelletizing chamber (where poultry manure pellets are generated), and high quality Siemens motor (which can drive the pellet machine and have a long service life), etc. It works similar to wood chip pellet machine.

Its main working principle is similar to that of the biomass pellet mill. The treated manure material enters into the pellet mill through the feeder, and is transformed into poultry manure pellets under the extrusion of the ring die and the pressure rollers, and is discharged from the discharge port. The desired pellet length can be obtained by adjusting the cutter device. In addition, different diameters of manure pellet diameters from 6-12mm are avaiable.

RICHI Machinery is an expert in feed, wood, biomass, and organic fertilizer pelletizing solutions, we design every pellet production line according to customers’ needs. We have provided thousands of customers from 127 countries with complete pelletizing projects. If you have any pelletizing needs, just send an inquiry to us.

middle banner

High quality poultry manure pellet machine make high-quality poultry manure pellets

Choose a high quality poultry manure pellet machine

Technical features of poultry manure pellet machine

  • No need of binder. Using organic pellets in a certain force, can set each other to grow up the characteristics of pelleting without the need to add binder.
  • Simple principle, fast pelletizing speed, high quality.
  • Wide source of materials. Mainly from livestock and poultry manure manure and urine, composting fertilizer, green manure, sea fertilizer, cake fertilizer, charcoal, soil fertilizer, three wastes, microbial waste and other municipal waste.
  • The machine is suitable for direct granulation of organic fertilizer after fermentation, saving the drying process, greatly reducing manufacturing costs.
  • The machine has the characteristic of high pelletizing strength, good appearance quality, corrosion resistance, wear resistance, low energy consumption, long service life and convenient operation and maintenance.
  • The machine granulation rate of more, smooth operation, equipment, durable, long service life, and by the majority of users to choose as the ideal product.
  • The poultry manure fertilizer granules making machine adopts stainless steel design, sturdy and durable, never deformed, coupled with a solid base design, so that its operation is more and smooth.
Technical features of poultry manure pellet machine

Various kinds of poultry manure pellet machine for sale

chicken manure pellets machine

chicken manure pellets machine

Capacity:
1-2T/H

Pellet Machine Power:
37KW

organic fertilizer pellet machine

organic fertilizer pellet machine

Capacity:
3-4T/H

Pellet Machine Power:
55KW

organic fertilizer pellet mill

cow dung pellet making machine

Capacity:
5-6T/H

Pellet Machine Power:
110KW

chicken manure pelleting equipment

chicken manure pelleting equipment

Capacity:
7-8T/H

Pellet Machine Power:
160KW

poultry manure compost pelleting machine

poultry manure compost pelleting machine

Capacity:
9-10T/H

Pellet Machine Power:
250KW

organic fertilizer granulating machine

organic fertilizer granulating machine

Capacity:
10-12T/H

Pellet Machine Power:
280KW

Here are the technical parameters of our poultry manure pellet machine for sale. If you don’t know how to choose, just contact us directly.

ModelMZLH320
Capacity(T/H)1-2
Main Motor Power(KW)37
Forced Feeder Power(KW)0.55
Ring Die Diameter (mm)320
Weight(KG)2500
ModelMZLH350
Capacity(T/H)3-4
Main Motor Power(KW)55
Forced Feeder Power(KW)0.55
Ring Die Diameter (mm)350
Weight(KG)3500
ModelMZLH420
Capacity(T/H)5-6
Main Motor Power(KW)110
Forced Feeder Power(KW)0.55
Ring Die Diameter (mm)420
Weight(KG)4000
ModelMZLH520
Capacity(T/H)7-8
Main Motor Power(KW)160
Forced Feeder Power(KW)0.75
Ring Die Diameter (mm)520
Weight(KG)4500
ModelMZLH768
Capacity(T/H)9-10
Main Motor Power(KW)250
Forced Feeder Power(KW)1
Ring Die Diameter (mm)768
Weight(KG)5000
ModelMZLH858
Capacity(T/H)10-12
Main Motor Power(KW)280
Forced Feeder Power(KW)1
Ring Die Diameter (mm)858
Weight(KG)5500

(Note: RICHI Machinery’s products are always updated and improved. Therefore, if there is any difference between the pictures, feature descriptions and performance parameters of the actual model, please refer to the actual product.)

poultry feed pellet making machine

Applications of poultry manure pellet machine

Poultry manure pellet machine has a wide range of application and stable operation, which is the ideal equipment for making poultry manure pellets. Its main applications are mainly in the following aspects:

  • Poultry manure pellet machine is able to handle a wide variety of animal manure raw materials, such as cow manure, chicken manure, horse manure, pig manure and so on. Besides, it can also be used as a biomass pellet mill, which can process almost all biomass raw materials.
  • Complete models and support customization. Suitable for organic fertilizer pellet plant and biomass pellet plant of all sizes.
  • The manure pellets produced can be used as organic fertilizer to provide nutrients for plants, and it is also an efficient, energy-saving and environmentally friendly biomass pellet fuel.

Many people may have this doubt: What is the price of the feed pellet machine or how much does a pellet mill cost? Then I will introduce you to the approximate price of the pellet machine below.

Production process of making pellets from poultry manure

The process of making poultry manure pellets is similar to poultry feed pellet production line, the difference is that before making poultry manure pellets, it is necessary to fully putrefy poultry manure before pelletizing.

Poultry manure pellet production process is generally: poultry manure putrefaction, crushing poultry manure, mixing poultry manure, poultry manure pelletizing, drying poultry manure, poultry manure pellet cooling, poultry manure pellet packing.

chicken manure pellet production line

01 Poultry manure decomposition

Decomposition of poultry manure is a very important step. Poultry manure needs to be fermented and decomposed first, and during the fermentation period, it needs to be turned over constantly with the help of organic fertilizer turning machine, to avoid insufficient supply of internal oxygen, or even anaerobic reaction affecting the rate of decomposition. The manure can be fully decomposed to maximize its use value.

02 Crushing poultry manure

First, the collected poultry manure is crushed. Because some poultry manure raw materials piled up for a long time, into large pieces, and the size is too large if it is not convenient to put into the pelletizer, which will affect the effect of pelletizing, and in serious cases, it may even be clogged and damage the pelletizer.

03 Mixing poultry manure

If your raw material state is different, then the treatment process is also different. Therefore, after the above crushing process, you can use the mixer to mix all the raw materials that you have set the formula of the material beforehand and then pelletize them together.

04 Poultry Manure Pelletizing

Once the manure has been putrefied, it can be fed into a pelletizer for pelletizing. The use of poultry manure pellet machine will be the chemical composition and poultry manure condensed together, can avoid the later transport process of nutrient differentiation, while poultry manure pellets are more conducive to storage and transportation, but also in line with the future development trend of the fertilizer market, suitable for mechanized fertilization.

Poultry manure fertilizer pelletizer machine is the key equipment for poultry manure pellet production, which directly determines the quality and output of poultry manure pellets. Therefore, it is crucial to choose a suitable poultry manure compost pelleting machine.

05 Poultry manure drying and cooling

Poultry manure pellets are dried and cooled after pelletizing, so as to link packaging and transportation and realize automatic continuous production. After the pelletizing process, you can screen and wrap the pellets according to your needs to further increase the economic value of the commodity.

RICHI Machinery is an expert in feed, wood, biomass, and organic fertilizer pelletizing solutions, we design every pellet production line according to customers’ needs. We have provided thousands of customers from 127 countries with complete pelletizing projects. If you have any pelletizing needs, just send an inquiry to us.

Benefits of poultry manure pellets

Benefits of poultry manure pellets

  • Poultry manure fertilizers with low water solubility usually have to be crushed into small pellets to ensure that they dissolve effectively and quickly in the soil and are taken up by plants.
  • Control of the size of poultry manure pellets is important for storage and transportation of the fertilizer. Good pelletizing makes poultry manure less likely to clump and has better transportation performance.
  • In the poultry manure pellet production line can add some inorganic components to improve the fertilizer efficiency of poultry manure organic fertilizer
  • Poultry manure pelleting improves the agricultural process, manure pellets play a role in the slow release of fertilizer effectiveness, and the application of fertilizer is convenient, not easy to be blown away by the wind.
  • Poultry manure pellets are highly mobile, easy to manage and reduce transportation and storage costs.
RICHI-banner

Why choose RICHI Machinery?

  • Devoted to the pellet machinery industry for 27years
  • All products have passed ISO, CE, SGS, BV, and other international certifications.
  • Have a perfect sales system and a complete service network
  • Can customize a turnkey pellet production line project according to your need.

Project cases related to poultry manure pellet machine

There are some of the pellet making project cases completed by RICHI Machinery related to poultry manure pellet machine for sale for your reference. If you want to know more about the turnkey projects we have delivered, you can see project case.

Poultry manure pellet production line project in China

Poultry manure pellet production line project in China

  • Country: China
  • Date: June 2016
  • Capacity: 8T/H
  • Total Power: 763KW
  • Workshop size about this project: 4325m²
  • The install period: 1 Month
  • The operate worker in this line: 5
  • Main equipment in this line: Poultry manure hammer mill, poultry manure mixing machine, poultry manure pellet machine for sale, high-quality screening machine, high-efficiency rotary drum dryer, poultry manure pellet cooling machine, automatic packaging machine, etc.
3-5T/H organic fertilizer pellet mill Production Line In Thailand

3-5T/H organic fertilizer pellet mill Production Line In Thailand

  • Country: Thailand
  • Date: Aug 27th,2018
  • Capacity: 3-5T/H
  • Total Power: 80KW
  • Workshop size about this project: 9m*3m*10m (L*W*H)
  • Main equipment in this line: organic fertilizer pellet machine, cooling machine, conveying equipment,etc.
  • Main Raw materials: chicken manure , rice husk
  • The install period: 10 Days
  • Number of installation engineers assisted by our company: 2 person
  • The operate worker in this line: 3 person
10 t/h poultry manure organic pellet production line

10 t/h poultry manure organic pellet production line

  • Country: China
  • Date: October 2021
  • Total Power: 1879KW
  • Workshop size about this project: 4600m²
  • Main equipment in this line: High efficiency poultry manure hammer mill, organic fertilizer pellet mill, rotary dryer, pellet poultry manure pelletcooling machine, automatic packing machine, conveying equipment, pulse dust collectors, etc.
  • Guiding Price: $1,000,000-$3,000,000
  • Customer’s final Pellet Size: 6-8mm
  • The install period: 2 months
  • The operating worker in this line: 6-7
5-6 T/H Organic Fertilizer Pellet Making Line In Pakistan

5-6 T/H Organic Fertilizer Pellet Making Line In Pakistan

  • Country: Pakistan
  • Date: December 8, 2021
  • Total Power: 238KW
  • Workshop size about this project: 15m*5m*10m (L*W*H)
  • Main equipment in this line: High efficiency hammer mill, mixing machine, chicken manure pelletzer, organic fertilier pellet cooling machine, packing machine,and other auxiliary equipment.
  • Raw materials: chicken manure, cattle manure
  • Customer’s final Pellet Size: 4mm
  • The install period: 20 Days
  • The operate worker in this line: 4
feed pellet machine for sale background

CUSTOM SOLUTIONS

—— GET A QUOTE ——

Accurate control of cost accounting, scientific calculation of expected profits, to achieve cost reduction and efficiency, profit can be expected.From equipment selection and program planning in the early stage

Checking Order

Quality Test Before Delivery

Check Items When Packing

Packaging And Transport

Training Support

After-sale Service

What raw materials are suitable for poultry manure fertilizer pelletizer machine?

Poultry manure pellet machine can process a variety of raw materials, such as livestock manure, pig manure, chicken manure and other organic materials, as well as straw, straw, wood chips, tree branches and other biomass materials. If you are not sure whether your raw materials can be used in poultry manure pelletizer processing, you can tell us your raw materials, we are happy to do free product testing for you.

How much does a poultry manure pellet machine cost?

The price of poultry organic fertilizer pellet machine is determined by many factors, among which the output of the pelletizer plays a decisive role, generally speaking, the same type of machine, the larger the output of the pelletizer, the more expensive the pelletizer price. The price of poultry manure pelletizer is generally between $15,000-$50,000. Factors affecting the price of pelletizer include brand, manufacturer, material, region and so on. So if you directly ask how much is the price of the pelletizer, this question may not be very good to answer you. You can tell us your production capacity requirements, our sales staff will contact you to send you a detailed quotation for pelletizer.

How does the poultry manure pellet machine work?

The structure of chicken manure pellet machine is similar to that of wood pellet mill, which consists of feeder, ring mold, pressure roller, motor and so on. Its working principle is also the same as the wood pellet machine, are crushed raw materials into the pelletizer feeder, the material through the feeder into the pelletizing chamber inside. In the pelletizing chamber, the material fills the inner wall of the ring die, and the final granular poultry manure pellets are extruded from the die hole under the extrusion of the ring die and pressure roller.

Where to buy poultry manure pellet machine?

Many people may ask, I already know enough about pelletizer, but where can I go to buy pelletizer? Generally speaking, there are two main ways to buy pelletizing machine online: mechanical e-commerce platforms and pelletizing machine manufacturers’ websites. You just need to Google poultry feed pelletizing machine, I believe that a very large number of pelletizing machine information will appear.
With the continuous development of the pelletizing machine industry, the number of pelletizing machine manufacturers in the market is also increasing day by day. But how to choose a reliable and professional one among these manufacturers is a headache. Let’s talk about how to choose a reliable pelletizer manufacturer!

How to choose a reliable poultry manure pellet machine manufacturer?

First of all, product quality must be the most important. No matter how attractive the price of the supplier provides, you must carefully assess the quality of the product before making a choice. Otherwise, buying back a poor quality chicken manure pellets machine may produce poor quality poultry manure pellets or even not work properly. Then you lose not only these monetary costs, but also time costs. Therefore, before comparing the price of the business, be sure to judge the quality of the granulator according to the details of the product. If possible, it is best to go to the granulator manufacturer’s plant to see the factory on the spot.
Secondly, the strength of the manufacturer. Is the manufacturer’s own production and processing or substitute processing? Generally speaking, if the manufacturer is responsible for its own production, it will have a full set of perfect services, and it can support customization. Can accurately according to your needs for you to design the most suitable machinery and equipment or even granulation production line. The strength of the manufacturer can be considered from the company’s operating time, customer feedback, the company’s patent certificate and other aspects.

Then, whether the after-sales service is perfect. Before choosing a granulator manufacturer, be sure to ask whether there is a perfect after-sales service. For example, whether the equipment sent over to provide installation guidance services? Whether to train the product operation and subsequent maintenance? And so on.
RICHI Machinery has 30 years of experience in the granulator industry and has served thousands of customers worldwide. Every one of our customers has appreciated us in the production of pelletizing machines and installation of pellet production lines. It is our honor to be recognized by our customers, but at the same time it is also due to our trustworthy strength. We believe that only by bringing you good products, we can cooperate and win together. Therefore, no matter you have any granulation needs, you can contact us for consultation, we are happy to help you!RICHI Machienry factory workshop
